datenmeister.web.navigation.uxf

The user has the following main navigation points:

  • Dashboard

  • Workspaces

  • Data Workspace

  • Settings

Web Forms

The following two forms are requested via the web:

ItemsOverview.cshtml -→ DetailFormCreator

  • Here, the function of the DetailFormCreator is called.

  • This calls the web API forms/default_for_item.

  • This calls CreateExtentFormForItem with the parameter: TreeItemDetail.

Items.cshtml

  • Here, the function of the CollectionFormCreator is called.

  • This calls the web API forms/default_for_extent.

  • This calls CreateExtentFormForExtent with the parameter: TreeItemExtent.

Web UI

The main window should contain the following areas:
